LD System LMEI100 G2 Additional In-Ear Monitor Receiver B6
LMEI100 G2 Additional In-Ear Monitor Receiver B6
LMEI100 G2 Additional In-Ear Monitor Receiver B6 - Receiver for LDMEI100 is a new In-Ear Monitoring-System with 96 UHF channels offers outstanding sound quality and a large dynamic range in the 655 – 679 MHz band. The system toggles between mono and stereo mode for perfect monitoring for live musicians, actors or speakers. A built-in limiter ensures even, distortion-free sound reproduction with a frequency response of 80Hz - 15 kHz and stands out because of its high signal-to-noise ratio and low total harmonic distortion. The LD MEI 100 G2 permits simultaneous operation of up to 5 systems. Both transmitter and receiver feature multifunctional displays that show all important system information. With high-quality batteries, it is possible to attain running times of 10 hours and more.
Features
- Consists of 9.5″ stereo transmitter MEI 100 T, body pack receiver MEI 100 G2 BPR, and earphones
- Up to 8 systems simultaneously
- Frequency range: 823 – 832 MHz and 863 – 865 MHz
- Integrated limiter up to +12 dB
- 2 jacks/XLR combination inputs
- Headphone output
- Operation with 2 AA batteries
- Detachable BNC antenna
- Includes rack mount, batteries, antenna cable for front mounting, and plastic case
Spec
Product number: LDMEI100G2BPRB6
Product type: In-ear Monitoring Accessories
Type: Receivers
Transmission frequency range: 655 – 679MHz
Channels: 96 (8 groups of 12 channels)
Transmission method: FM, stereo
Frequency response: 80 – 15000Hz
THD: 0.25 %
Audio output: 3.5 mm TRS
Max. audio output level: 100mW
Controls: up, down, Set, volume
Indicators: LC display, RF (LED)
Operating voltage: 2 x 1.5 V AA
Operating time: > 10 hrs.
Width: 65mm
Height: 95mm
Depth: 25mm
Weight: 0,1kg
Features: incl. batteries
