LD Systems Stinger 12 A G3 12″ Powered Speaker



LD Systems Stinger 12 A G3

The LD Systems Stinger 12 A G3 powered speaker is engineered for rock-solid reliability day in, day out. With its multi-purpose bass reflex construction and carefully contoured, user-friendly presets it is equally suitable for full-range, satellite or floor monitor applications. The Stinger® 12 A G3 is powered by high-efficiency Class D amplification with a hefty 500 watts RMS output. It drives a custom-designed 12” woofer and BMS compression driver delivering a punchy low end and smooth, crisp highs. The HF wave-guide has been designed using BEM, the numerical modeling of sound radiation and propagation. It reduces floor and ceiling reflections, effectively eliminates side lobes and achieves a controlled uniform coverage pattern. The Stinger12A G3 also incorporates LD Systems’ proprietary DynX® DSP technology to ensure top-level performance with maximum clarity and punch at all times. Processing includes crossover and multi-band limiter functions for accurate time alignment and pristine, distortion-free audio. Designed to be a real workhorse throughout, the enclosure is made of rigid birch ply and coated with ultra-tough polyurea for extraordinary strength and durability. Sporting a steel front grille, Dual-Tilt pole receptacle, multiple suspension points and ergonomic handles the Stinger12 A G3 is an attractively priced choice for truly professional sound reinforcement. A large selection of accessories facilitates live and installed applications.

Features

• High performance 12″ powered speaker
• Full range 2-way design
• Onboard 500W (RMS) Class-D amplifier
• On button mode selection to suit various applications
• Strong wooden enclosure with Polyurea coating
• Integrated multi-band limiter
• Great for FOH or foldback applications
• Designed and engineered in Germany

Spec

Product number: LDEB122AG3

Product type: PA loudspeaker

Type: active

Low/mid driver: 12″ (304mm)

Woofer voice coil: 2.5″

Horn: BEM optimized CD Horn

HF driver: 1″ BMS

HF driver voice coil: 1″

Amplifier: Class D

Inputs: 2x XLR / Jack combo

Outputs: 1x XLR

Dispersion (H x V): 90 x 50°

RMS: 500W

Peak power: 1000W

Frequency response: 58Hz to 20kHz

Max. SPL: 131dB (peak)

Protection circuits: over voltage, Multiband limiter, thermal overload, over-current

Input sensitivity: -5dBu

Indicators: mode, protect (protection circuit engaged), signal, Mic, on, limit

Operating voltage: 240V / 50Hz

Operating Temperature: 0 – 40°C

Relative humidity: < 80% (non-condensing)

Cabinet material: 15 mm Plywood

Dimensions: 390 x 627 x 377mm

Weight: 20.6 kg
